A Series
Thru Floor – Electric Traction
Full Height Cabin with Swing Door
3 persons
2 levels
Speed – 0.08m/s
C Series
Standardised Electric Traction
Swing or Sliding Door models in stock
4 persons
2-4 levels
Speed – 0.30m/s
E Series
Custom Italian Luxury
Swing or Sliding Doors
4-7 persons
2-7 levels
Speed – 0.30m/s – 0.60m/s
| A Series | C Series | C+ Series | E Series | E+ Series | |
|---|---|---|---|---|---|
| Style | Thru floor | Standard Electric Traction | Custom Electric Traction | Pre - Engineered - Hydraulic | Custom Hydraulic |
| Lead Time *Stock and labour availability vary | Held in Stock | Fast - 10 weeks | Fast | Pre-Engineered - 4-5 months * | Custom Built - 5-6 months * |
| Best for *Stock and labour availability vary | 2 level lift quickly | 2 - 4 levels, | 2 - 6 levels, - Custom Traction Drive | 2 - 4 levels | 2 - 6 levels, - Custom Hydraulic Drive |
In Car Rescue System | Yes | Yes | Yes | Yes | Yes |
Price Guide (2 Levels) Due to many options, prices are indicative | $36,000 + | $45,000 + | $47,000 + | $41,000 + | $49,000 + |
| Drive Type Options | Electric Only | Electric Only | Electric Only | Hydraulic | Hydraulic |
| Capacity | 2 - 3 persons 255kg | 7 Persons 500kg | 7 Persons 500kg | 4 - 6 persons 300kg - 400kg | 4 - 6 persons 300kg - 400kg |
| Place of Origin | Europe | Europe | Europe | Europe | Europe |
| Doors | Swing Door | Sliding Door | Swing Door Sliding Door | Swing Door Sliding Door | Swing Door Sliding Door |
| Suitable Locations | Private Home Indoor Use Only | Private Home | Private Home | Private home or | Private home |
Inclusions | 1 month Free Storage GSM unit | 2055mm cabin ceiling height Scaffold for lift installation GSM unit | 1 month free storage 2055mm cabin ceiling height Scaffold for lift installation GSM unit | 1 month free storage 2100mm cabin ceiling height Scaffold for lift installation GSM unit | 1 month free storage 2100mm cabin ceiling height Scaffold for lift installation GSM unit |
Maximum Number of floors | 2 | 4 9m | 6 15.1m | 4 | 6 15.1m |
Cabin Sizes | Small Medium Large | 1000mm x 1000mm 1000mm x 1200mm 1100mm x 1400mm | Custom Sizing | 1000mm x 1000mm | Custom Sizing |
Brochures | Brochure | Italian Swing Door Brochure Italian Sliding Door Brochure | Italian Swing Door Brochure Italian Sliding Door Brochure | ||
Pit Depth | None | 180mm | 180mm | Hydraulic 150mm | Hydraulic 150mm |
Drawings | Small Medium Large | 1000mm x 1000mm 1000mm x 1200mm 1100mm x 1400mm | Swing Door Drawings Sliding Door Drawings | Swing Door Drawings Sliding Door Drawings | Swing Door Drawings Sliding Door Drawings |
| Shaft Options | Not required as | Shaft by Builder | Shaft by Builder | Shaft by Builder | Shaft by Builder |
| Speeds | 0.08 | 0.30m/s | 0.30m/s | 0.30m/s | 0.30m/s |
Internal Cabin Ceiling Height | 1900mm | 2055mm | 2055mm | 2100mm | 2100mm |
Car Door | Yes - full height | Sliding Door - Yes - fully enclosed | Swing Door - No – Infrared sensors provided Sliding Door - Yes - fully enclosed | Swing Door - No – Infrared sensors provided Sliding Door - Yes - fully enclosed | Swing Door - No – Infrared sensors provided Sliding Door - Yes - fully enclosed |
Cabin configurations | Single Opening Only | Single / Opposite/ Adjacent Opening | Single / Opposite/ Adjacent Opening | Single / Opposite/ Adjacent Opening | Single / Opposite/ Adjacent Opening |
Minimal Headroom | 2400mm | 2800mm | 2800mm | 2400mm - 2700mm | 2400mm - 2700mm |
Power Requirements | Single Phase | Single Phase | Single Phase | Single Phase | Single Phase Three Phase |
Drive Machinery Location | Contained in system | Electric: Within system above lift | Electric: Within system above lift | Hydraulic: Small Cabinet near lift | Hydraulic: Small Cabinet near lift |
